mr-DWL series

Contact Person

3800
Dr. Anja Voigt
E-Mail: a.voigt@microresist.de
Phone: +49 30 64 16 70 100
3802
Anja Hinz
E-Mail: a.hinz@microresist.de
Phone: +49 30 64 16 70 100
Negative resists for direct laser writing @ 405 nm
Permanent application and conventional pattern transfer processes
Unique Features
  • Sensitive above 400 nm, for direct writing laser @ 405 nm
  • High thermal and chemical stability
  • High wet and dry etch stability
Applications
  • Fast and contactless prototyping by
  • Permanent: Master/ template manufacture, mould for PDMS
  • Pattern transfer: Etch mask, mould for electroplating
Parameter
Resist Film tickness
mr-DWL 5 5.0 µm @ 3000 rpm
mr-DWL 40 40 µm @ 2000 rpm
mr-DWL 100 100 µm @ 1500 rpm



quotation request

Clear

Lithographic Services & Application Engineering

Based on our product portfolio and extensive hands-on experience, we offers lithographic micro and nanopatterning services.
Tech-blog

Optical 3D patterning by greyscale lithography and UV moulding

An excellent method for the manufacturing of optical 3D structures is grayscale patterning of positive resist ma-P 1200G and subsequent pattern transfer by UV moulding using OrmoStamp® and OrmoComp®.
Tech-blog
